Technical parameters:
No. | Item | Parameter | Remark | |
1 | Suitable material | Type | Color steel, galvanized steel | |
Thickness(mm) | 0.3-0.6mm | 235MPA | ||
Yield strength (Mpa) | ≤300mm | 235Mpa | ||
Width (mm) | About 1220mm | |||
2 | Forming speed | Roofing sheet 15-20 m/min | Not include cutting time | |
3 | Motor of forming system (kw) | 7.5kw | ||
4 | Hydraulic station power(kw) | 4kw | ||
5 | Voltage requirements | AC380V, 50Hz, 3phase | According to customer’s request | |
6 | Shaft diameter | 70mm | ||
7 | Roller material | 45# steel with heat treatment 58-62 degree | ||
8 | Drive method | 1.0 inch chain | ||
9 | Machine structure body | 350mm H beam | ||
10 | PLC system | Delta digital touch screen PLC | ||
11 | Roller station | 18-20 rows | ||
Process Flow Chart
Decoiler --- guiding system --- roll forming --- cut to length --- product to supporting table
